Round-the-clock public safety operations - police, fire and EMS - can be extremely demanding for both personnel and equipment. The NX-5000 Series radios are robust and offer clear mission-critical communications in numerous environments - even with sirens in the background. Advanced emergency features, such as man-down detection and ease of operation, even with gloves, make NX-5000 Series radios the perfect choice to enhance safety in the line of duty.
Thanks to multi-digital operation, NEXEDGE® offers a flexible communications system that is ideal for a wide range of industries and fields - ranging from utilities and traffic agencies to schools, taxi services and security companies. What's more, top-of-the-line features such as the transflective display for easy viewing in sunshine, GPS capability and Bluetooth® connectivity all contribute to enhanced efficiency and cost-effectiveness. From top to bottom, the NX-5200, NX-5300, and NX-5400 Series radios mean business.
Frequency Band:
VHF/UHF/700MHz/800MHz
Frequency Range:
136-174 MHz / 450-520 MHz, 380-470 MHz / 763-776, 851-870 MHz
Power Output:
1W – 6W / 1W – 5W / 1W – 3W
Standard battery chemistry type:
Li-ion
Battery life (based on a 5-5-90 duty cycle):
11 Hours
Number of Channels/Groups/Zones:
1024 Channels / 128 Zones (Up to 4,000 with option)
Channel spacing:
12.5 / 15 / 25 / 30 kHz, 12.5 / 25 kHz Analog
6.25 / 12.5 kHz Digital
Dimensions W x H x D (with standard battery)
2.28 x 5.47 x 1.56 in
Weight (with standard battery)
14.3 oz
Keypad / Keys
4-way Directional-pad (D-pad) and 2-Position Lever Switch
Display
Large, Color 1.74" (240 x 180 pixels) Transflective TFT Display
Operating temperature
-22°F to +140°F
Mil spec
MIL-STD-810 C/D/E/F/G
IP Standards
IP54/55/67/68
 | KRA-22M VHF low-profile antenna 148-162 MHz |
| KRA-22M VHF low-profile antenna 162-174 MHz |
| KRA-22M VHF Low-profile helical antenna 136-150 MHz |
 | KRA-23M UHF low-profile antenna 450-490 MHz |
| KRA-23M2 UHF low-profile antenna 470-520 MHz |
| KRA-23M3 UHF Low-profile helical antenna 403-430 MHz |
 | KRA-25 High-gain VHF helically loaded whip antenna 148-162 MHz |
 | KRA-26M VHF helical antenna 146-162 MHz |
| KRA-26M2 VHF helical antenna 162-174 MHz |
| KRA-26M3 VHF helical antenna 136-150 MHz |
 | KRA-27M UHF whip antenna 440-490 MHz |
| KRA-27M2 UHF whip antenna 470-520 MHz |
| KRA-27M3 UHF whip antenna 400-450 MHz |
| KRA-28 Broadband VHF helically loaded whip antenna 140-170 MHz |
| KRA-29 Broadband UHF Whip Antenna 380-430 MHz |
 | KRA-32K 700/800 MHz Whip Antenna |
| KRA-36 700/800 MHz Stubby Antenna |
| KBP-8M AA Alkaline Refillable Battery Pack (12 AA: 9V). Cells not included. |
| KNB-L1M Li-ion 2000mAh (Compact Slim) |
| KNB-L2M Li-ion 2600mAh (Standard) |
| KNB-L3M Li-ion 3400mAh (High Capacity) |
| KNB-LS5CU CSA US Intrinsically Safe Battery Li-ion 2000mAh |
| KNB-LS7M CSA US Intrinsically Safe Battery Li-ion 3800mAh |
| KNB-N4M Ni-MH 2500mAh |
 | KSC-32 Rapid-rate single-unit charger for KNB-31A/32N/33L/41NC/43L/47L/48L/50NC |
 | KSC-326AK Rapid-rate 6-unit charger CEC Compliant |
| KSC-Y32K Rapid-rate single-unit charger (Long-Life Charge Mode capable with KAS-12 Software) |
 | KVC-15 Rapid-rate DC vehicular charger adapter for the KSC-32 (chargers not included; includes KSC-mobile bracket & cigarette lighter cable DC adapter) |
| KVC-23 Rapid-rate DC vehicular charger for TK-5x10/5x20, NX-5x00/x00/x10/x20, TK-x180, TK-x170, & TK-x360 portables with Lithium Ion/Lithium Polymer/NiMH packs only |
 | KBH-11 Spring action belt clip (2.5") |
| KBH-8DS Leather swivel belt loop with portable D-Ring attachment |
| KLH-137ST Firemen's Heavy-Duty Leather Shoulder Strap for a Heavy-Duty Leather Case (KLH-75B/76B/78B/79B//92/122/123/133/148/154) |
| KLH-200K3 Heavy-duty leather carrying case for NX-5000 Series with KNB-L1/L2/L3/LS5CU(for both keypad models) |
| KLH-201K3 Nylon carrying case for NX-5000-series with KNB-L1/L2/L3/LS5CU(for both keypad models) |
| KLH-6SW Leather swivel belt loop / detachable swivel D-Ring back |
| KCT-51 Hirose 6-pin Adapter (adapts KVL/aftermarket audio acc. to portable connector)[Intrinsically Safe Approved Accessory] |
 | KEP-1 3.5mm earphone kit for KMC-48GPS Speaker Mics |
 | KEP-2 2.5mm earphone kit for KMC-17/45D Speaker Mic[KEP-2 & KMC-21 are not plug-compatible] |
| KHS-11BL 2-wire palm mic w/earphone, universal connector (Black) [Intrinsically Safe Approved Accessory] |
| KHS-12BL 3-wire mini lapel mic w/earphone, universal connector (Black) [Intrinsically Safe Approved Accessory] |
| KHS-14 Lightweight Single muff headset w/boom mic & In-line PTT [Intrinsically Safe Approved Accessory] |
| KHS-15D-BH Heavy-duty noise reduction behind-the-headset w/noise canceling boom mic & in-line PTT [Intrinsically Safe Approved Accessory] |
| KHS-15D-OH Heavy-duty noise reduction over-the-headset w/noise canceling boom mic & in-line PTT [Intrinsically Safe Approved Accessory] |
| KMC-42WDM MIL-SPEC, IP67 (Immersion) Noise-canceling Speaker Mic [Intrinsically Safe Approved Accessory] |
| KMC-49 MIL-SPEC, Speaker Microphone with Antenna Connector |
| KMC-54WDM MIL-SPEC, IP67 (Immersion) Speaker Mic Compatible with ANR Feature |
| KWD-OH-5000 Orange Housing Kit for NX-5000 Series Portables (Standard Key Model K2/K5 Only) |
| KWD-YH-5000 Yellow Housing Kit for NX-5000 Series Portables (Standard Key Model K2/K5 Only) |
Standard Key Models
Full Key Models
CSA US APPROVED MODELS
